Vintage Heart with Modern Playability

The McCarty 594 is a versatile, vintage-inspired instrument that is effortlessly playable. Featuring a bound 22-fret Pattern Vintage neck and slightly thicker back for more enhanced tone and sustain, the McCarty 594 plays in tune, is intonated the entire length of the neck, and feels like a guitar you’ve been playing forever. Whether you are looking for rich, authentic humbucking tones or nuanced, sweet single-coil sounds, the McCarty 594 can seamlessly master both sonic territories thanks to its 58/15 LT pickups, which have now been through the TCI (tuned capacitance and inductance) process, and dual volume and push/pull tone controls. A zinc two-piece bridge and vintage-style tuners anchor this guitar and stay true to the promise of the McCarty family.

“One of my sayings is that everything that touches the string is God – well, that’s really the bridge, the nut, and the tuners. The updates to the McCarty family make a huge difference in their tone. The guitar sustains longer and the tone has more character,” said Paul Reed Smith.

In the late 1980’s, Paul Reed Smith called on Ted McCarty to consult with him on guitar design and production techniques. He not only served as a mentor but became a great friend of Paul and everyone he met at PRS. In 1994, PRS released the first McCarty, an instrument that incorporated the full spectrum of techniques and knowledge Paul had gained from Ted as well as his own experiences as a guitar builder.

Featured Specifications

Specifications

Body
Body Construction Solidbody
Top Wood Maple
Back Wood Mahogany
Top Carve Violin
Finish High Gloss Nitro
Neck
Number of Frets 22
Scale Length 24.594”
Neck Wood Mahogany
Neck Construction One-Piece
Truss Rod PRS Double-Acting
Neck Shape Pattern Vintage
Neck Depth at the 1/2 Fret 7/8"
Neck Depth at the 12 1/2 Fret 63/64"
Neck Width at the Nut 1 11/16"
Neck Width at the Body 2 1/4"
Fretboard Wood Rosewood w/ Faux Bone Binding
Fretboard Radius 10"
Fretboard Inlay Birds
Headstock Logo Signature, Inlaid
Neck/Body Assembly
Neck/Body Assembly Type Set
Hardware
Bridge PRS Two-Piece
Tuners Vintage-Style
Hardware Type Nickel
Nut Bone
Truss Rod Cover "McCarty"
Electronics
Treble Pickup 58/15 LT
Bass Pickup 58/15 LT
Controls Two Volume and Two Push/Pull Tone Controls with 3-Way Toggle Pickup Switch
Additional Info
Strings PRS Signature 10-46
Tuning Standard (6 String): E, A, D, G, B, E
Case Hardshell Case
Options 10 Top with Hybrid Hardware

Controls

Infographic showing switching positions for McCarty 594

McCarty 594 - Controls Description

3-way toggle pickup switch

Position 1 (down) - treble pickup

Position 2 - treble and bass pickups

Position 3 (up) - bass pickup

Push/pull tone pots

Down - humbucker mode

Up - single coil mode

Colors

Antique White*

Antique White*

Black*

Black*

Black Gold Burst

Black Gold Burst

Charcoal

Charcoal

Charcoal Burst

Charcoal Burst

Dark Cherry Sunburst

Dark Cherry Sunburst

Faded Whale Blue*

Faded Whale Blue*

Gold Top

Gold Top

McCarty Sunburst

McCarty Sunburst

McCarty Tobacco Sunburst

McCarty Tobacco Sunburst

Red Tiger

Red Tiger

Yellow Tiger

Yellow Tiger
